100kg/h
200kg/h
300kg/h
400kg/h
500kg/h

Small Banana Chips Production Line

Capacity :30-500kg/h customzied as your need.

Material :Food Grade 304 Stainless Steel

Production Name :Small Banana Chips Production Line

All cooperative partners operate well

Automatic French fries production line

Specialized In R&D For French fries production

Capacity :100-2000kg/h customzied as your need.

Material :304 Stainless Steel

Production Name :Automatic French fries production line

All cooperative partners operate well

Automatic French fries production line

Specialized In R&D For French fries production

Capacity :100-2000kg/h customzied as your need.

Material :304 Stainless Steel

Production Name :Automatic French fries production line

All cooperative partners operate well

Automatic French fries production line

Specialized In R&D For French fries production

Capacity :100-2000kg/h customzied as your need.

Material :304 Stainless Steel

Production Name :Automatic French fries production line

All cooperative partners operate well

Automatic French fries production line

Specialized In R&D For French fries production

Capacity :100-2000kg/h customzied as your need.

Material :304 Stainless Steel

Production Name :Automatic French fries production line

All cooperative partners operate well

Product Description

Hash browns are a potato product made from fresh potatoes as the main ingredient, processed through multiple steps including washing, cutting, seasoning, shaping, and frying. The hash browns production line can be flexibly configured according to customer needs, capable of producing both ready-to-eat crispy hash browns and frozen hash browns.

Main Processing Steps in Hash Browns Production Line:

1, Potato washing and peeling

After fresh potatoes enter the hash browns production line, they first undergo washing and peeling. This production line utilizes a combination of water jets and mechanical friction to effectively remove dirt, impurities, and the outer skin from the surface of the potatoes, ensuring clean and hygienic raw materials.

2,Shredding / Chopping

Washed and peeled potatoes are processed through cutting equipment to be shredded or chopped. The cutting size and shape can be adjusted according to the recipe requirements of different hash brown products, ensuring a consistent texture and firm structure in the finished product.

3, Seasoning and Mixing

Using mixing equipment, various ingredients such as salt, spices, starch, and other auxiliary components are uniformly mixed to enhance the flavor of the potato cakes.

4, Shaping

The hash browns are pressed into a fixed shape and thickness using a patty forming machine. Common shapes include round, oval, or custom mold shapes. The uniform size facilitates subsequent frying or freezing processes, and also simplifies product packaging and sales.

5. Frying

Continuous frying equipment allows for precise control of temperature and time, enabling the hash browns to quickly set and form a golden, crispy crust while locking in moisture, ensuring excellent texture and appearance.

6. Quick Freezing (Optional)

Hash browns are a potato product made from fresh potatoes as the main ingredient, processed through multiple steps including washing, cutting, seasoning, shaping, and frying. The hash browns production line can be flexibly configured according to customer needs, capable of producing both ready-to-eat crispy hash browns and frozen hash browns.



Configuration Parameter

Device machine

Power(kw)

Dimensions(mm)

Forming

1.5

700 630*950

Forming

1.1

900*850*1000

Conveying

24

1000*500*1000

Cooling

1.5

1000*600*740

Freezing-IQF

36

1200*1000*1200

Advantage

It capacity is about 50-150kg/h, This process line is preferable for small chips making business,And it is an ideal opportunity for you to start your ow business.

 High degree of automation

The production line adopts a continuous and automated design, ensuring a smooth flow from raw material processing to finished product output.

 Strong product adaptability

By changing cutting and forming molds and adjusting process parameters, the hash brown production line can process hash brown of various specifications and shapes.

Tailor-Made Solutions

A reliable process line is a success factor for your potato chips making business, We offer customized turnkey solutions for you to get the optimum result.

9371dadb6375afdd90c39f1315e4dd66
Great Flexibility

In the small banana chips plant, all the machines specially designed so that they can be easily installed, cleaned and maintained.

Application

  • People can use it in many places, such as small process enterprise, food factory, etc.

  • It is can be used for all kinds of root vegetables and fruits, potato, carrot, apple, banana etc.
